187(4.8) Terminal Series


Update time:2019-05-14 08:27

Specifications:

nothing

*Temperature range:(including temperature rise in applying electrical current)
*Compliant with RoHS.


■4.8  187 Premier type

    Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		 Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1871-001515 Brass 0.35 26-22 0.13-0.33 1.3-1.7 5.70 15.50 6.50 Tin-Plated 0.50 10K
TP1871-002525 Brass 0.35 22-18 0.33-0.75 1.7-2.8 5.70 15.50 6.50 Tin-Plated 0.50 10K
TP1871-003535 Brass 0.35 20-18 0.5-0.75 2.6-2.8 5.70 15.60 6.50 Tin-Plated 0.50 10K
TP1871-013535 Phosphor BronzeBronze 0.35 20-16 0.5-1.5 2.6-3.5 5.70 15.00 6.50 Tin-Plated 0.50 8K
TP1871-013535 Brass 0.35 20-16 0.5-1.5 2.6-3.5 5.70 15.50 6.50 Tin-Plated 0.50 8K
TP1871-004445 Brass 0.35 16-14 1.25-2.5 3.5-4.0 5.90 19.30 9.60 Tin-Plated 0.50 6K
TP1871-014545 Brass 0.35 16-14 1.25-2.5 3.5-4.0 5.70 19.30 9.60 Tin-Plated 0.50 6K
TP1871-012525 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.70 15.30 6.30 Tin-Plated 0.50 10K
TP1871-002828 Brass 0.35 20-18 0.5-0.75 2.6-2.8 5.70 15.50 6.50 Tin-Plated 0.80 10K
TP1871-003838 Brass 0.35 18-16 0.75-1.25 2.8-3.5 5.70 15.50 6.50 Tin-Plated 0.80 10K
TP1871-013838 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.70 15.00 6.50 Tin-Plated 0.80 8K
TP1871-004848 Brass 0.35 16-14 1.25-2.5 3.5-4.0 5.90 19.30 9.60 Tin-Plated 0.80 6K



Applicable sleeve











Part No. Material Q'ty/reel Part No. Material L Q'ty/reel Part No. Material Q'ty/reel Part No. Material Q'ty/reel
H187P-0101 PA66 1K H187P-0102 PA66 20 500 H187P-0302 PA66 500 H187S-01011 PVC 2K
H187P-0202 PA66 24.2 500 H187S-02011 PVC 2K
H187S-03011 PVC 2K



■4.8 187 Premier type with positive lock
       Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1872-002525 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.7 17.5 6.3 Tin-Plated 0.5 10K
TP1872-002525 Phosphor BronzeBronze 0.30 20-16 0.5-1.25 2.6-3.5 5.7 17.5 6.3 Tin-Plated 0.5 10K
TP1872-003535 Brass 0.35 18-16 0.75-1.25 2.8-3.5 5.7 17.5 6.3 Tin-Plated 0.5 8K
TP1872-001515 Brass 0.35 24-22 0.22-0.33 1.5-1.7 5.7 17.5 6.3 Tin-Plated 0.5 10K
TP1872-002828 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.7 17.5 6.3 Tin-Plated 0.8 10K
TP1872-002828 Phosphor BronzeBronze 0.30 20-16 0.5-1.25 2.6-3.5 5.7 17.5 6.3 Tin-Plated 0.8 10K
TP1872-003838 Brass 0.35 18-16 0.75-1.25 2.8-3.5 5.7 17.5 6.3 Tin-Plated 0.8 8K
TP1872-003838 Phosphor BronzeBronze 0.30 18-16 0.75-1.25 2.8-3.5 5.7 17.5 6.3 Tin-Plated 0.8 8K
TP1872-002424 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.7 17.5 6.3 Tin-Plated 0.4 10K
TP1872-001414 Brass 0.35 24-22 0.5-1.25 2.6-3.5 5.7 17.5 6.3 Tin-Plated 0.4 10K



Applicable sleeve
Part No. Material Q'ty/reel
H187S-01011 PVC 2K
H187S-02011 PVC 2K
H187S-03011 PVC 2K



■4.8 187 Microwave oven type
          Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1870-703535 Brass 0.30 18-16 0.75-1.25 2.8-3.5 5.70 20.30 5.00 Tin-Plated 0.5 6K
TP1872-702525 Brass 0.30 20-18 0.5-0.75 2.6-2.8 5.70 20.00 5.00 Tin-Plated 0.5 10K
TP1872-704545 Brass 0.30 16-14 1.25-2.5 3.5-4.0 5.70 20.10 5.00 Tin-Plated 0.5 6K



Applicable sleeve


Part No. Material Q'ty/reel Part No. Material Q'ty/reel Part No. Material Q'ty/reel Part No. Material Q'ty/reel Part No. Material Q'ty/reel Part No. Material Q'ty/reel
H187P-04011 PA66 1K H187P-04022 PA66 1K H187P-05022 PA66 1K H187P-06022 PA66 1K H187P-07022 PA66 1K H187P-08033 PA66 1K



■4.8 Short flag type

        Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1874-0025 Phosphor BronzeBronze 0.3 20-16 0.5-1.25 2.6-3.5 6.2 12.1 5.6 Tin-Plated 0.5 10K
TP1874-002828 Phosphor BronzeBronze 0.3 20-16 0.5-1.25 2.6-3.5 6.2 12.1 5.6 Tin-Plated 0.8 10K



Applicable sleeve


Part No. Material Q'ty/reel
H187S-05011 PVC 2K
H187S-06011 PVC 2K



■4.8 187Flag type
                               Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1874-0135 Brass 0.35 18-16 0.75-1.25 2.5-3.5 5.7 14.0 6.6 Tin-Plated 0.5 5K
TP1874-013838 Brass 0.35 18-16 0.75-1.25 2.8-3.5 5.7 14.0 6.6 Tin-Plated 0.8 5K
TP1874-014848 Brass 0.35 16-14 1.25-2.5 3.5-4.0 5.7 14.7 6.6 Tin-Plated 0.8 5K
TP1874-012828 Brass 0.35 22-20 0.33-0.5 1.7-2.6 5.7 14.0 6.6 Tin-Plated 0.8 5K



Applicable sleeve


Part No. Material Q'ty/reel
H187S-06011 PVC 2K



■4.8 187C-Crimp
        Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1873-003535 Brass 0.35 18-14 0.75-2.5 2.8-4.0 5.7 12.7 6.6 Tin-Plated 0.5 5K
TP1873-003838 Brass 0.35 18-14 0.75-2.5 2.8-4.0 5.7 12.7 6.6 Tin-Plated 0.8 5K


Applicable sleeve



Part No. Material Q'ty/reel Part No. Material Q'ty/reel
H187P-0902 PA66 1K H187S-04011 PVC 2K
H187S-0501 PVC 2K



■4.8 187 C-Crimp flag type with

         Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1873-603535 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.7 13.8 6.4 Tin-Plated 0.5 5K
TP1873-603838 Phosphor BronzeBronze 0.30 20-16 0.5-1.25 2.6-3.5 5.7 13.2 5.6 Tin-Plated 0.8 5K
TP1873-603838 Brass 0.35 20-16 0.5-1.25 2.6-3.5 5.7 15.0 6.4 Tin-Plated 0.8 5K




Applicable sleeve


Part No. Material Q'ty/reel Part No. Material Q'ty/reel
H187P-10011 PA66 1K H187S-06011 PVC 2K



■4.8  187 Piggyback type

 		     Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1871-302525 Brass 0.35 20-16 0.5-1.25 2.6-3.5 6 16.1 6.2 Tin-Plated 0.5 4K
TP1871-304545 Brass 0.35 18-14 0.75-2.5 2.8-4.0 6 16.1 6.2 Tin-Plated 0.5 4K
TP1871-302828 Brass 0.35 20-16 0.5-1.25 2.6-3.5 6 16.1 6.2 Tin-Plated 0.8 4K
TP1871-304848 Brass 0.35 18-14 0.75-2.5 2.8-4.0 6 16.5 6.2 Tin-Plated 0.8 4K



■4.8  187 Piggyback type with positive lock


 		     Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E
TP1872-303838 Brass 0.4 18-16 0.75-1.5 2.8-3.5 5.7 16.0 6.4 Tin-Plated 0.8 1400
TP1872-303535 Brass 0.4 18-16 0.75-1.5 2.8-3.5 5.7 16.0 6.4 Tin-Plated 0.5 1400


■Other type
         Part No.    Material   Thickness
Applicable wires
 		  Wire insulation
O.D. mm		   Dimensions（mm）

Plating

 Mating Tab Q'ty/reel
AWG# mm²

W

 L E


TP1871-7028


28		 Brass 0.3 22-18 0.33-0.75 1.7-2.8 5.1 15.0 7.0 Acid  Picking 0.8 5K

 		 TP1871-713232 Phosphor BronzeBronze 0.4 18-16 0.75-1.25 2.8-3.5 5.1 18.5 8.5 Tin-Plated 2.0 5K

 		 TP1873-703232 Phosphor BronzeBronze 0.4 18-16 0.75-1.25 2.8-3.5 5.1 14.8 8.5 Tin-Plated 2.0 5K
